The PTFE gate valve seat seal is made of durable teflon, it is used in rotating equipment to minimize o-ring movement.
Brand:
JST SealsItem NO.:
ESJPayment:
T/TProduct Origin:
ChinaShipping Port:
GuangzhouOrder(MOQ):
50PTFE gate valve seat seal
The PTFE gate valve seat seal is made of durable teflon, it is used in rotating equipment to minimize o-ring movement.
Wellhead sealing ring is a key sealing component for wellhead equipment. The typical sealing applications include wellhead gate valve, wellhead plug valve, wellhead choke valve, wellhead and Christmas tree. They can be exposed to harsh fluids to high temperature, pressure and contact forces. In this case, the performance of the seal and how long it lasts largely depend on the choice of sealing materials.
Seal technology is committed to improving the efficiency and safety of on-site operation. Various seal rings can be designed and manufactured according to user requirements.
 |
Advantages: 1.Cost-effective |
| Working Conditions | ||||
| Working Pressure | Working Temperature | Working Medium | Material | |
| 0~15000 PSI | PU | Hydraulic fluids, crude oil, sour oil/gase, H2S, salty water | Filled PTFE/PEEK | |
Application Suggestion:
FC, FLS valve
Size:
 |
|||
|
Valve Nominal Diameter
|
Pressure Level | ||
| Inch | MM | PSI | Mpa |
| 1-13/16" | 46 | 10K/15K | 70/105 |
| 2-1/16" | 52 | 2K/3K/5K/10K/15K | 14/21/35/70/105 |
| 2-9/16" | 65 | 3K/5K/10K/15K | 21/35/70/105 |
| 3-1/16" | 78 | 10K/15K | 70/105 |
| 3-1/8" | 80 | 2K/3K/5K | 14/21/35 |
| 4-1/16" | 103 | 3K/5K/10K/15K | 21/35/70/105 |
| 5-1/8" | 130 | 5K | 35 |
| 6-3/8" | 162 | 3K/5K | 21/35 |
| 7-1/16" | 180 | 3K/5K | 21/35 |
| 7-1/16" | 180 | 3K/5K/10K | 35/70/105 |
If you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.
